Description
| AMO-5G10 | |
|---|---|
| Dimensions (mm) | 582 x 90 x 65 mm |
| Weight | 0.68 kg |
| Frequency Range | 5.45 – 5.85 GHz |
| Gain | 10 dBi |
| Elevation Beamwidth | 12° |
| Max. VSWR | 1.6:1 |
| Downtilt | 4° |
| Wind Survivability | 125 mph |
| Wind Loading | 10 lb @ 100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
