Description
| AMO-2G13 | |
|---|---|
| Dimensions (mm) | 1390 x 122 x 105 mm |
| Weight | 2.4 kg |
| Frequency Range | 2.35 – 2.55 GHz |
| Gain | 13 dBi |
| Elevation Beamwidth | 7° |
| Max. VSWR | 1.7:1 |
| Downtilt | 2° |
| Wind Survivability | 125 mph |
| Wind Loading | 16 lb @ 100 mph |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 25 dB min. |
| ETSI Specification | EN 302 326 DN2 E |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
