Description
| Mechanical | |
|---|---|
| Dimensions | 413 x 413 x 320 mm (16.26 x 16.26 x 12.60″) |
| Weight | Without mount: 1.4 kg (3.09 lb) With mount: 1.8 kg (3.97 lb) |
| Enclosure materials | Aluminum, UV-stabilized polycarbonate |
| Mount | Pole mount (included) |
| Wind loading | 420 N at 200 km/h (94.4 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Hardware | |
| Networking interface | (1) 10/100/1000 MbE RJ45 port |
| Power method | Passive PoE (pins 4, 5+ and 7, 😎 |
| Power supply | 24V DC, 0.5A Gigabit PoE adapter (included) |
| Voltage range | 22—26VDC |
| Max. power consumption | 11W |
| Antenna gain 5 GHz 60 GHz |
11 dBi 38 dBi |
| ESD/EMP protection | Air/contact: ± 24kV |
| GPS | Yes |
| LEDs | Power/Ethernet/5G/60G/GPS |
| Operating temperature | -40 to 60° C (-40 to 140° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| OS | airOS® |
| Maximum throughput | 1.9 Gbps |
| Maximum range | 2+ km |
| Encryption | WPA2-PSK (AES)/WPA2 Enterprise |
| Management interface | UISP application (web/mobile) |
| Minimum software requirements | Any modern web browser/iOS™ or Android™ based smartphone |
| Radio | |
| Max. conducted TX power 5/60 GHz combined | 25 dBm |
| Channel bandwidth* 60 GHz 5 GHz |
2160, 1080* MHz 20/40/80 MHz * Depends on regulatory region. |
| Operating Frequency (Mhz) | |
| US/CA U-NII-1 U-NII-3 |
5150 – 5250 5725 – 5850 57,000 – 66,000 |
| Worldwide | 5180 – 5875 57,000 – 66,000 |
| Management Radio (MHz) | |
| Worldwide | 2412 – 2472 |
| US/CA | 2412 – 2462 |
