Description
| Specifications | |
|---|---|
| Dimensions | 201.3 x 128.0 x 32.5 mm (7.93 x 5.04 x 1.28″) |
| Weight | Without mount: 400 g (14.1 oz) With mount: 480 g (16.9 oz) |
| Enclosure Characteristics | Outdoor UV Stabilized Plastic |
| RF Connections | (2) RP-SMA |
| Supported Frequency Range | 2.4-2.5 GHz, 5.1-5.9 GHz |
| Mounting | Wall/Pole (Kits Included) |
| 2.4 GHz Band | |
| Gain | 10 dBi |
| HPOL Beamwidth | 90° |
| VPOL Beamwidth | 90° |
| Elevation Beamwidth | 90° |
| Maximum VSWR | 2:1 |
| Polarization | Dual-Linear |
| Cross-Pol Isolation | 25 dB |
| 5 GHz Band | |
| Gain | 15 dBi |
| HPOL Beamwidth | 45° |
| VPOL Beamwidth | 45° |
| Elevation Beamwidth | 45° |
| Maximum VSWR | 2:1 |
| Polarization | Dual-linear |
| Cross-Pol Isolation | 30 dB |
